Glasline Touch series
Glasline Touch — duplex, with indicator, two buttons
Article code U30DB0005
Glass-front landing fixture with capacitive touch actuation. This configuration: duplex, with indicator, two buttons, horizontal, white.
EN 81-20EN 81-70
| Mounting | Flush mounted |
|---|---|
| Group control | Duplex |
| Indication | With indicator |
| Call buttons | Two buttons |
| Button layout | Horizontal |
| Front finish | White |
| Actuation | Touchless |
| Width | 190 mm |
| Height | 320 mm |
| Depth | 6 mm |
Configuration options
- Straightforward installationFront assembly and fixing points designed for fast mounting on site.
- Selectable indicationSeven-segment, dot-matrix, LCD or TFT indication depending on configuration.
Request a quote for this product
Quote the article code U30DB0005 in your message so the position can be matched directly.
Dimensions
Variants and dimensions
Dimensions as published for this configuration. Confirm against the existing opening before ordering a retrofit position.
| Article code | Type | Width | Height | Depth |
|---|---|---|---|---|
| U30DB0005 | Front | 190 mm | 320 mm | 6 mm |
| U30DB0005 | Back | 153 mm | 260 mm | 35 mm |
