Lumen — with indicator, white — landing call panel, product view

Lumen series

Lumen — with indicator, white

Article code U20SM0081

Surface-mounted landing fixture with a white illuminated front. This configuration: with indicator, white.

EN 81-20EN 81-70
Specification
MountingSurface mounted
IndicationWith indicator
Front finishWhite
ActuationMechanical push button

Configuration options

  • Straightforward installationFront assembly and fixing points designed for fast mounting on site.
  • Configurable front finishMirror, satin, black or grey panel surfaces on request.
  • Configurable button finishButton surfaces matched to the panel front.
  • Serial and parallel interfacesAvailable for parallel wiring and for serial-communication control systems.
  • Selectable indicationSeven-segment, dot-matrix, LCD or TFT indication depending on configuration.
  • Emergency lightingIntegrated emergency illumination in the panel front.
  • Custom engravingPanel engraving and illuminated logo to the customer artwork.
  • Communication module optionPrepared for an integrated emergency-call and status-reporting module.
Request a quote for this product

Quote the article code U20SM0081 in your message so the position can be matched directly.

Ordering

Interface variants

Where a configuration exists for more than one control interface, each variant carries its own article code.

Further interface codes

Drive-controller busU20SM0082
Serial communicationU20SM0083
